Advanced Progressive Die Design & Sheet Hlau Tooling Layouts
Puas yog koj tawm tsam nrog kev noj zaub mov tsis ruaj khov, cov khoom pov tseg ntau dhau, lossis nquag noj misfeeds hauv koj cov txheej txheem stamping tam sim no? Lub hauv paus ua rau yuav luag ib txwm pom nyob rau hauv thawj lub cuab yeej engineering theem.
Peb muab cov ntaub ntawv - tsavProgressive tuag tsimcov kev daws teeb meem uas hloov cov ntaub ntawv nyuaj rau hauv siab -ceev, rov ua tau, thiab ultra- txhim khu kev lag luam stamping. Los ntawm kev ua kom zoo dua qhov kev txhim kho dawb paug thiab kev txhim kho ntawm cov kauj ruam ib, peb pab thoob ntiaj teb stampers txo cov nqi seem thiab ua kom siab tshaj xovxwm uptime.
Technical Engineering: Yuav Ua Li Cas Peb Txhim Kho Koj Cov Txheej Txheem Txheej Txheem
Kev vam meejProgressive tuag layoutsib npaug siv cov khoom siv nrog lub zog lub cuab yeej. Peb pab pawg engineering siv cov txheej txheem Formability Simulation Software los txheeb xyuas kev ntxhov siab, thinning, thiab springback ua ntej ib qho thaiv ntawm cov hlau yog machined.
[Cov Neeg Siv Khoom 3D Tshooj] ➔ [DFM & Formability Analysis] ➔ [Strip Layout Optimization] ➔ [3D Tool Design]
Yam Tseem Ceeb Peb daws Thaum Tsim:
Material Yield Optimization:Peb suav cov nested pitching xaiv los nyem qhov ntau tshaj plaws ntawm qhov chaw tawm ntawm txhua lub kauj.
Carrier Wave Stability:Tsim cov cab kuj muaj zog uas tiv thaiv kab nrib pleb los yog buckling thaum lub sij hawm siab - pub mis ceev.
Idler Station Strategic Placement:Tawm hauv qhov chaw tsis muaj qhov tseem ceeb kom tso cai rau kev hloov kho yooj yim lossis kev saib xyuas siab - coj cov ntxig tom qab.
Engineering Standards & Compatibility
Pebsheet hlau tuag tsimcov kev pab cuam seamlessly integrate nrog koj cov txheej txheem toolroom uas twb muaj lawm thiab xovxwm specifications.
| Engineering Parameter | Txhawb Cov Qauv / Cov Qauv |
| Software Platforms | Logopress, UG NX, Autoform (Simulation), SolidWorks |
| Ntiaj teb no Standards | NAAMS (Automotive), DIN, JIS, ISO |
| Component Integrations | Misumi, Danly, FIBRO, Dayton, Punch |
| Cov ntaub ntawv xa tuaj | Cov ncauj lus kom ntxaws 3D cov rooj sib txoos (.STEP / .IGS), 2D Nto moo Drawings (.DWG) |
Tshwj xeeb hauv High-Challenge Tooling Architecture
Tsis yog tag nrho cov cuab yeej nce qib yog tsim sib npaug. Peb cov ntaub ntawv tsim qauv npog cov txheej txheem tshwj xeeb uas yuav tsum tau ua rau cov txheej txheem nyuaj, nruj - kam rau ua:
Hauv -Tuag Tapping & Inserting
Tshem tawm cov kev ua haujlwm thib ob uas kim heev. Peb tsim cov tshuab lossis servo-tsav nyob rau hauv-cov tapping tuag thiab tsis siv neeg kho vajtse ntxig tshuab ncaj qha rau hauv cov cuab yeej sib lawv liag.
Cam-Action & Side-Piercing
Rau qhov uas yuav tsum tau muaj qhov, qhov, los yog cov ntaub ntawv perpendicular rau cov xovxwm stroke, peb siv heev check aerial los yog tuag-mounted cam systems featuring engineered rov strokes.
High-Speed Electronic Connectors
Tsim qauv qauv, carbide- ntxig tuag rau ultra- cov ntaub ntawv nyias (mus txog 0.1mm) khiav ntawm 500+ strokes ib feeb (SPM).
🛑 Engineering Diagnostic Check
Puas yog koj cov cuab yeej uas twb muaj lawm raug kev txom nyem los ntawm kev tawg ntxov ntxov lossis hnyav burrs? Peb cov engineers tuaj yeem ua tiavcuab yeej tsim tshuaj xyuasntawm koj daim phiaj xwm tam sim no txhawm rau txheeb xyuas cov chaw nres tsheb tsis muaj zog, tshem tawm tsis raug, lossis tsis txaus lub caij nplooj ntoos hlav roj.
Npaj rau Streamline koj qhov project stamping tom ntej?
Tsis txhob nkim sijhawm rau kev sim-thiab- yuam kev prototyping. Koom tes nrog ib qho engineering- thawj pab neeg uas nkag siab yuav ua li cas tsim cov cuab yeej rau -lub ntiaj teb xovxwm khw. Xa peb koj cov ntaub ntawv 3D ib feem (.STEP lossis .IGS) nrog rau koj cov xovxwm specs, thiab peb yuav xa ib daim kab xev ua ntej.
