Kev xaiv cov khoom & Durability
| Qeb yam khoom | Cov khoom nyiam | Hardness (HRC) | Cov ntsiab lus thov |
| Qib hwm | DC53 / SKH-9 NPE | $60 - 64$ | Siab- nrawm, siab- ntim ntau lawm |
| Standard Qib | SKD11/D2 | $58 - 62$ | General Industrial Cheebtsam |
| Qib Economic | Cr12MOV | $55 - 58$ | Luv -cov ntaub ntawv siv los yog tuab dua |
| Tuag Base | S50C / 45 # Hlau | $180 - 220$ HB | Kev txhawb nqa thiab kev ruaj ntseg |
Tooling peev xwm
Max Tuag Dimensions:Mus txog $3500 \\text{mm} \\times 1500 \\text{mm}$
Stamping Thickness:$0.2 \\text{mm}$ to $12 \\text{mm}$
Xovxwm Compatibility:$25\\text{T}$ rau $1200\\text{T}$ Mechanical/Hydraulic presses
Tolerance Control:Linear $\\pm 0.01\\text{mm}$, Angular $\\pm 0.5^\\circ$
Tso zis hom:2D (DWG, DXF), 3D (STP, STEP, IGS)
Core Zoo
Siab -Txoj Cai Rigidity
Txhuastamping pwmyog tsim los nrog ib tug reinforced tuag teeb kom tshem tawm deflection thaum lub sij hawm downward stroke. Qhov rigidity no yog qhov tseem ceeb rau kev tswj xyuas qhov concentricity ntawm punched qhov thiab lub sharpness ntawm sheared npoo.
Advanced Thermal Processing
Peb tsis yog "kub kho" peb cov hlau xwb. Peb sivNqus quenching thiab cryogenic kholos xyuas kom meej ib tug uniform martensitic qauv. Qhov no txhais tau tias yog ib lub cuab yeej uas tsis yog ua haujlwm xwb- nws kav ntev, tiv taus chipping thiab abrasive hnav.
Sensor-Kev nyab xeeb sib xyaw
Txhawm rau tiv thaiv tus nqi "ob npaug- hits" lossis misfeeds, peb tuaj yeem muab cov khoom siv hluav taws xob sib txuas rau hauv koj qhov kev tuag. Qhov cuab yeej ntse no tiv thaiv koj cov peev txheej thiab txo cov nqi seem.
Optimized Scrap Management
Peb cov qauv tsim muaj qhov ua tau zoo-kev tsim cov slug tshem tawm thiab huab cua- pab raws kom ntseeg tau tias cov khoom seem poob kom huv si, tiv thaiv "slug rub" uas tuaj yeem ua rau cov khoom ua haujlwm puas tsuaj lossis qhov tuag.
Tag Nrho -Cycle Manufacturing Process
Kev tshuaj xyuas engineering:Peb ua tag nrhoTooling Feasibility Studyntawm koj 3D qauv.
CNC & EDM Machining:Siab -milling ceev thiab qeeb- taug kev hlau txiav rau cov khoom tseem ceeb.
Precision Assembly:Master toolmakers tes- haum cov khoom kom ntseeg tau tias kev sib raug zoo.
T1 Kev sim khiav:Peb sim cov pwm hauv cov xwm txheej uas simulate koj qhov chaw tsim khoom tiag tiag.
Kev soj ntsuam zoo:Kev txheeb xyuas siv CMM (Coordinate Measuring Machine) thiab optical projectors.
7. FAQ
Q: Yuav ua li cas koj lav lub neej ntawm stamping pwm?A: Txhua lub pwm yog xa nrog phau ntawv saib xyuas thiab kev lees paub mob stroke suav. Peb siv cov khoom lag luam zoo tshaj plaws thiab muab cov khoom seem tseem ceeb (punches, springs, inserts) nrog rau thawj cov khoom xa tuaj.
Q: Koj puas tuaj yeem ua cov ntaub ntawv siab - tensile lub zog?A: Yog. Rau cov ntaub ntawv zoo li stainless hlau lossis siab - lub zog tsheb hlau, peb siv cov txheej txheem tshwj xeeb (TICN/TD) thiab hnyav- lub caij nplooj ntoos hlav lub luag haujlwm los tswj cov kev xav tau ntau dua.
Q: Nws puas tuaj yeem hloov kho qhov tuag tom qab thawj cov qauv?A: Peb txoj kev tsim qauv qauv tso cai rau kev hloov kho me me hauv qhov ntev lossis geometry yam tsis tas yuav rov tsim kho tag nrho lub hauv paus tuag.
